Specification Min. operating weight (kg) 7300 Track width (mm) 1435 Wheelbase (mm) 1792 Track shoe width (mm) 390 Ground pressure (kPa) 47.7 (with dozer blade) Diesel Model LR6A3Z-22 Type In-line, liquid-cooled, four-stroke, turbocharged Nominal power and rotation speed (kW/rpm) 95.6/2200 Transmission Gear shifting (forward/reverse) 6/2 Speed range (km/h)(forward/reverse) 3.71-13.90/3.31-6.28 PTO power (kW) 81 PTO speed (rpm) 540/1000 Grab Double disc, single acting Working device Suspension type Rear two-point or three-point suspension (type II) Method of controlling the depth of plowing Adjustable height Lifting force (kN) 14.6 Dimensions of the bulldozer blade (W×H)(mm) 2462×850 Dozer blade immersion depth (mm) 330
| Specification | |
| Min. operating weight (kg) | 7300 |
| Track width (mm) | 1435 |
| Wheelbase (mm) | 1792 |
| Track shoe width (mm) | 390 |
| Ground pressure (kPa) | 47.7 (with dozer blade) |
| Diesel | |
| Model | LR6A3Z-22 |
| Type | In-line, liquid-cooled, four-stroke, turbocharged |
| Nominal power and rotation speed (kW/rpm) | 95.6/2200 |
| Transmission | |
| Gear shifting (forward/reverse) | 6/2 |
| Speed range (km/h)(forward/reverse) | 3.71-13.90/3.31-6.28 |
| PTO power (kW) | 81 |
| PTO speed (rpm) | 540/1000 |
| Grab | Double disc, single acting |
| Working device | |
| Suspension type | Rear two-point or three-point suspension (type II) |
| Method of controlling the depth of plowing | Adjustable height |
| Lifting force (kN) | 14.6 |
| Dimensions of the bulldozer blade (W×H)(mm) | 2462×850 |
| Dozer blade immersion depth (mm) | 330 |
