GE210H 21 Ton Crawler Excavator

Main technical characteristics
Element	Unit
Nominal Standard Bucket Capacity (SAE Standard)	m3	0.91
Operating weight	Kg	21000
Measurement
Length (during transport)A	mm	9520
Width (during transport) (with 600 mm track) B	mm	2800
Height (transport)）C	mm	3030
Height (to top of cabin)E	mm	2958
Ground clearance of counterweight F	mm	1025
Min. ground clearance H	mm	470
Rear turning radius	mm	2800
Min. front turning radius	mm	3560
Distance between wheels of track J	mm	3370
Track width M	mm	2200
Standard track shoe width N	mm	600
Operating range
Max. digging depth B	mm	6690
Max. vertical digging depth C	mm	6104
Max. bucket reach A	mm	9953
Max. digging depth on ground A’	mm	9794
Max. digging height D	mm	9642
Max. discharge height E	mm	6813
Diesel
Model		Cummins 6BTAA5.9-C150
Type		6 cylinders. 4 strokes. Water cooling. Turbocharged with direct injection.
Number of cylinders - Intercylinder diameter X Piston stroke	mm	6-102X120
Nominal power	hp (kW)/rpm	150(112)/1950
Max. torque	Kgf.m/rpm	62.6/1500
Nominal speed	rpm	1950
