Annealing machines heat the rope with an electric current, which allows the rope to be twisted and separated. The result is a rounded end that does not flare and can be easily inserted into fittings.
RD series steel rope annealing machine with high melting speed and easy operation is suitable for melting steel ropes of various sizes, especially elevator, mine, crane and other high-quality steel ropes. The melted steel ropes are neat and smooth, with tapered and spiral ends. These machines are mainly used by steel rope manufacturers and customers.
Features of the rope annealing and cutting machine:
1. Convenient shape and ease of movement.
2. Due to the wide range of melting diameters, steel ropes can be melted without replacing any parts within a given diameter.
3. Easy to operate, no wrench required to tighten the device, the welding head has a nice appearance.
4. Low working power, energy saving and safe to use.
Technical specifications of the rope annealing and cutting machine
No. RD-1010 RD-1011 RD-1012 RD-1013 Nominal power (kW) 5 kW 12 kW 50 kW 100 kW Burnout range 3-16 mm 6-32 mm 20-40 mm 28-60 mm Dimensions (mm) 700x400x1200 700x800x1150 1600x1200x1800 1600x1200x1800 Weight 75 kg 260 kg 550 kg 600 kg
Annealing machines heat the rope with an electric current, which allows the rope to be twisted and separated. The result is a rounded end that does not flare and can be easily inserted into fittings.
RD series steel rope annealing machine with high melting speed and easy operation is suitable for melting steel ropes of various sizes, especially elevator, mine, crane and other high-quality steel ropes. The melted steel ropes are neat and smooth, with tapered and spiral ends. These machines are mainly used by steel rope manufacturers and customers.
Features of the rope annealing and cutting machine:
1. Convenient shape and ease of movement.
2. Due to the wide range of melting diameters, steel ropes can be melted without replacing any parts within a given diameter.
3. Easy to operate, no wrench required to tighten the device, the welding head has a nice appearance.
4. Low working power, energy saving and safe to use.
Technical specifications of the rope annealing and cutting machine
| No. | RD-1010 | RD-1011 | RD-1012 | RD-1013 |
| Nominal power (kW) | 5 kW | 12 kW | 50 kW | 100 kW |
| Burnout range | 3-16 mm | 6-32 mm | 20-40 mm | 28-60 mm |
| Dimensions (mm) | 700x400x1200 | 700x800x1150 | 1600x1200x1800 | 1600x1200x1800 |
| Weight | 75 kg | 260 kg | 550 kg | 600 kg |
