Four-column hydraulic press Woda.
The hydraulic pump uses 9 plungers.
The oil cylinder is made using three layers using special technology.
High pressure vacuum cleaning and shot blasting of hydraulic oil tanks
Piston rod/medium frequency hardening+precision grinding+hard chrome plating
The four-column hydraulic press is economical and practical. The hydraulic control uses a built-in cartridge valve system to reduce leakage points. It has a reliable action and a long service life. It can realize two molding processes of constant pressure and fixed stroke. The pressure holding delay function and the working pressure stroke can be within the specified range. It is adjusted within the range by the centralized control button, which can realize three working modes: manual, semi-automatic and automatic.
1. Various types of hydraulic press jack lower cylinders can be customized.
2. Buffer damping device
3. PLC touch screen control shunt
4. High-speed liquid filling device.
5. 20T---1000T can be specially customized according to customer's requirements.
※ Function: This series of hydraulic press is suitable for the pressing process of plastic materials, such as stamping, bending, flanging, fine stretching, etc. It can also be used for correcting, pressing, pressing and molding plastic products and powder products.
