1. High energy saving, efficiency, reliability and comfort.
2. All load-bearing parts of the drive axle are strong and reliable enough to ensure excellent overload resistance and meet the requirements of various high-strength and high-load operations.
3. As the only energy-saving product with low-speed engine among 3-ton forklifts in the industry, it leads the energy-saving trend in the industry.
4. The full-view cabin sufficiently takes into account the human-machine functions to ensure high operating safety and comfort.
5. Adhering to the concept of "ground service", all service places are scientifically arranged to facilitate inspection and maintenance.
Product parameters
Description Unit Parameter value Nominal working load kg 3000 Bucket capacity m³ 1.5~2.5 Machine weight kg 10900±200 Unloading clearance at maximum lift mm 2770~3260 Reach at maximum lift mm 1010~1210 Wheelbase mm 2900 Tread mm 1850 Hinge height at maximum lifting height mm 3830 Working height (fully raised) mm 4870 Max. breakaway force kN 130 Max. horsepower kN 95 Increased hydraulic cycle time With 5.4 Total hydraulic cycle time With 9.3 Min. turning radius over tires mm 5170 Articulation angle ° 38±1 Climbing grade ° 28 Tire size 17.5-25-12PR Model WP6G125E201 Emission standards Issue 2 Nominal power/speed kW/rpm 92/2000 Fuel tank L 170 Hydraulic tank L 175
1. High energy saving, efficiency, reliability and comfort.
2. All load-bearing parts of the drive axle are strong and reliable enough to ensure excellent overload resistance and meet the requirements of various high-strength and high-load operations.
3. As the only energy-saving product with low-speed engine among 3-ton forklifts in the industry, it leads the energy-saving trend in the industry.
4. The full-view cabin sufficiently takes into account the human-machine functions to ensure high operating safety and comfort.
5. Adhering to the concept of "ground service", all service places are scientifically arranged to facilitate inspection and maintenance.
Product parameters
| Description | Unit | Parameter value |
| Nominal working load | kg | 3000 |
| Bucket capacity | m³ | 1.5~2.5 |
| Machine weight | kg | 10900±200 |
| Unloading clearance at maximum lift | mm | 2770~3260 |
| Reach at maximum lift | mm | 1010~1210 |
| Wheelbase | mm | 2900 |
| Tread | mm | 1850 |
| Hinge height at maximum lifting height | mm | 3830 |
| Working height (fully raised) | mm | 4870 |
| Max. breakaway force | kN | 130 |
| Max. horsepower | kN | 95 |
| Increased hydraulic cycle time | With | 5.4 |
| Total hydraulic cycle time | With | 9.3 |
| Min. turning radius over tires | mm | 5170 |
| Articulation angle | ° | 38±1 |
| Climbing grade | ° | 28 |
| Tire size | 17.5-25-12PR | |
| Model | WP6G125E201 | |
| Emission standards | Issue 2 | |
| Nominal power/speed | kW/rpm | 92/2000 |
| Fuel tank | L | 170 |
| Hydraulic tank | L | 175 |
