Aquilo F1T-26-080-09

Kанальный конвектор - Aquilo F1T-26-080-09

Write to the Author
Aquilo F1T-26-080-09
Category:
Equipment for heating, ventilation and air conditioning systems
Subcategory:
Equipment
Keywords:
Not specified
Dimensions:
Length:
800
Width:
260
Height:
90
Diameter:
Not specified
Weight:
6
Category:
Equipment for heating, ventilation and air conditioning systems
Subcategory:
Equipment
Keywords:
Not specified
  • Dimensions
  • Files
alt
Files:
Select files to download
purmo_aquilo_f1t-90.rfa
purmo_proekt.rvt
f1t-26-080-09.ifc
Description
Версия Revit 2016. Семейство выполнено в двух уровнях детализации с УГО в плане и 3D-виде по ГОСТ 21.205-2016
