Aquilo FMK-42-080-14

Kанальный конвектор - Aquilo FMK-42-080-14

Write to the Author
Aquilo FMK-42-080-14
Category:
Equipment for heating, ventilation and air conditioning systems
Subcategory:
Equipment
Keywords:
Not specified
Dimensions:
Length:
800
Width:
420
Height:
140
Diameter:
Not specified
Weight:
11
Category:
Equipment for heating, ventilation and air conditioning systems
Subcategory:
Equipment
Keywords:
Not specified
  • Dimensions
  • Files
alt
Files:
Select files to download
purmo_proekt.rvt
fmk-42-080-14.ifc
purmo_aquilo_fmk-140.rfa
Description
Версия Revit 2016. Семейство выполнено в двух уровнях детализации с УГО в плане и 3D-виде по ГОСТ 21.205-2036
