GX216 Manual Wood Chipper

Technical parameters
Model GX216
Feeder size 230×500
Maximum feed diameter 230 mm
Main power 55 kW
Flying knives 2 pcs
Chip size 30 mm
Capacity 5-6 Tons
Oil pump capacity 1.5×1

1. The gap of the wood chipper knives of the hand wood chipper can be adjusted, then the output chip size will be adjusted.

2. Manual wood chipper chipper contains 4 meters feeding belt conveyor, the conveyor speed can be adjusted when transporting logs. Also, the wood chipper can contact with the output belt conveyor to transport the chips after crushing. The output belt conveyor can be installed at the bottom of the wood chipper or at the back of the wood chipper.

3. Manual wood chipper The wood chipper has knives, the knives do not need to be changed often. As a rule, the knives need to be sharpened per shift, they need to be changed after about 3-5 months.

4. The knife roller of the manual wood chipper is the main working part and is made of welded steel plate. It has good rigidity and moment of inertia. Also, the knife roller passes the dynamic balance test and works stably during operation.

5. Manual wood chipper shredder has a limit size of the feeding door, such as GX216, the feeding door size is 23*50cm, it means that the diameter of the raw logs should be less than 23cm, but the length is not a limitation, the feeding speed can be adjusted.
