Power voltage transformer

The transformer converter is a kind of new product designed by SIMENS company, which is in line with such standards as VDE0550, IEC439, GB5226 and so on. It is suitable for AC power grid frequency of 50~60Hz, output rated voltage less than 220V, input rated voltage less than 500V, used as control power supply for mechanical equipment and general electrical equipment, as power supply for working light and signal lamp.

Model	Output power	Output current	Measurement	Weight
	(KVA)	(A)	(L×W×H) cm	(Kg)
BK－0.5	0.5	2	13×13×14	4.7
BK-1	1	4.5	15×15×14	7.6
BK－1.5	1.5	7	18×19×21	10.5
BK-2	2	9	20×19×21	13
BK－2.5	2.5	11	21×19×21	17
BK-3	3	13.6	22×19×22	20
BK-4	4	18	23×23×25	26
BK-5	5	23	25×23×25	29
BK-8	8	36	24×29×30	38
BK-10	10	45	26×29×30	42
BK-15	15	68	27×36×45	61
BK-20	20	91	29×36×45	76
BK-25	25	114	29×38×50	95
BK-30	30	136	30×40×50	114
BK-40	40	181	32×45×55	152
BK-50	50	227	33×50×60	200
