Rubric:
Category:
Number of min. release of goods:
1
Publication date:
12.06.2024
| Maximum rotation diameter (MM) - 380
Tool installation method - Extended row knife + power head
| Maximum processing time -250
Square knife holder - 20x50
Chuck size - 6"
| Tool holder with round hole - Ф20
Spindle speed - 1-4500
Motor power X/Z axis - 1.3
|Spindle motor power - 7.5
Power head design - End iron 1 with 2 gears (double short shaft) - Side tip 1 with 2 gears (1 long and 1 short)
Through hole of spindle - Ф56
Power head motor power - Standard 1.3/ (optional 1.8)
Central height - 56
Power head speed - 0-4500
X\Z axis movement - 1040/270
Central height of loading rack - 1120
High speed movement along the X/Z axis - 30
|Total power - 15.5
Repeat positioning accuracy along X/Z axes - ±0.003
| Maximum rotation diameter (MM) - 380
Tool installation method - Extended row knife + power head
| Maximum processing time -250
Square knife holder - 20x50
Chuck size - 6"
| Tool holder with round hole - Ф20
Spindle speed - 1-4500
Motor power X/Z axis - 1.3
|Spindle motor power - 7.5
Power head design - End iron 1 with 2 gears (double short shaft) - Side tip 1 with 2 gears (1 long and 1 short)
Through hole of spindle - Ф56
Power head motor power - Standard 1.3/ (optional 1.8)
Central height - 56
Power head speed - 0-4500
X\Z axis movement - 1040/270
Central height of loading rack - 1120
High speed movement along the X/Z axis - 30
|Total power - 15.5
Repeat positioning accuracy along X/Z axes - ±0.003
