MAXIMUM rotation diameter (MM) 400
X/Z axis travel 720/250
Maximum processing length (MM) 220
High speed movement along the X/Z axis 3
Chuck size 6"
X/Z axis repeat positioning accuracy 0.003
Spindle speed 45-4500
Number of customizable tools 8
Spindle motor power 5.5
Shank size 20×20
Through hole of spindle Ф56
Tool size without perforation F20
|Spindle tip A2-5
|Total power 9
|Maximum diameter of automatic feed rod Ф45
