Maximum processing length (MM) 150
X2.Z2 axis servo motor power 1.3/0.85
Spindle nose A2-4 (type 36)
Square knife holder 20x20
Nasal end of dorsal axis A2-4 (type 36)
Tool holder with round hole Ф20
Tool holder center height 90
Rear Shaft Cylinder Armor Type 161E Push Forward
Spindle speed 0-4500
Slide guide form Linear guide
Through hole of spindle Ф46
High speed movement along the X/Z axis 24
Spindle motor power 5.5
Hydraulic station engine power 1.5
Rear shaft engine power 5.5
Water pump motor power 180
Movement along the X1\Z1\X2\Z2 axis 800/200
Total power 18
X1\Z1\X2\Z2 axis servo motor power 1.3/0.85
The net weight of the machine is about 4500
Machine size (L×W×H) (MM): 2060×1600×1820
Maximum processing length (MM) 150
X2.Z2 axis servo motor power 1.3/0.85
Spindle nose A2-4 (type 36)
Square knife holder 20x20
Nasal end of dorsal axis A2-4 (type 36)
Tool holder with round hole Ф20
Tool holder center height 90
Rear Shaft Cylinder Armor Type 161E Push Forward
Spindle speed 0-4500
Slide guide form Linear guide
Through hole of spindle Ф46
High speed movement along the X/Z axis 24
Spindle motor power 5.5
Hydraulic station engine power 1.5
Rear shaft engine power 5.5
Water pump motor power 180
Movement along the X1\Z1\X2\Z2 axis 800/200
Total power 18
X1\Z1\X2\Z2 axis servo motor power 1.3/0.85
The net weight of the machine is about 4500
Machine size (L×W×H) (MM): 2060×1600×1820
